Configure and Install Your PC/104-GPIB

Step

Note

If you plan to perform HS488 high-speed protocol transfers, you must configure the NI-488.2

software for the amount of GPIB cable length in your system. You must add the 20 in. GPIB ribbon

cable to your total GPIB cable length.

6. Check the installation.

7. Power on your system and start Windows.

Questions and Answers:

Need help?

Do you have a question about the NI GPIB Series and is the answer not in the manual?

NI GPIB Series Specifications

General

Operating Systems Supported	Windows, Linux, macOS
Driver Software	NI-488.2
Bus Interface	IEEE 488
Data Transfer Rate	Up to 8 MB/s
Compatibility	IEEE 488.1, IEEE 488.2
Connector Type	24-pin IEEE 488 connector
Maximum Cable Length	20 m total system length
Number of Devices Supported	Up to 14 devices per bus
