PMC-GPIB Installation
Next
Step
Previous
Step
73
Figure 18. Installing the PMC-GPIB
1 Host Face Plate
2 PMC-GPIB Board
3 +5 V Voltage Key
4 Mounting Screws
1
4
2
3
