Chassis System 18Service Manual – SC2000
Chassis System
Frame (main parts)
Reference to Figure 1
• Steering assembly/column support plate and deck mount
• Main support side member
• Gearmotor support plate and squeegee system mount
Steering assembly/column support
plate and deck mount
Gearmotor support plate and
squeegee system mount
Figure 1
Main support side member
