Scrub System, Disc 73Service Manual – SC2000
Specications
Description / Model
Advance / Nilsk
SC2000 53 B
Advance / Nilsk
SC2000 53 B FULL PKG
Cleaning width 21 in (530 mm)
Brush/pad diameter 21 in (530 / 508 mm)
Brush pressure with extra pressure function turned off 33 lb (15 kg)
Brush pressure with extra pressure function turned on 66 lb (30 kg)
Brush deck right/left offset 65 / 15 mm (2.5 / 0.6 in)
Brush distance from the oor (when lifted) 1.6 in (40 mm)
Brush motor power 0.6 hp (450 W)
Brush rotation speed 155 rpm
Protection class IP 20
Insulation class F
Actuator technical data
Spring load
105 ÷ 155 N
Regulated travel
2.6 in (66 mm)
Total travel
3.6 in (98 mm)
Maximum speed
16 mm/s
Voltage
24V
Protection class
IP 44
Insulation class
A
