CLINOX PRO • AIR • POWER • SURFACE
USER MANUAL
4.4. mm
• Install the insert on the torch (see chapter 4.2).
• Fold the felt into a "U" shape and slide it into the ns with grooves (A) on the electrode.
• Fasten the felt in place using the O-ring (B).
4.5. mm
• Install the insert on the torch (see chapter 4.2)
• Fold the felt into a "U" shape and stick it on to the electrode.
• Fasten the felt in place using the O-ring (A).
