CLINOX PRO • AIR • POWER • SURFACE
USER MANUAL
• Choose the most appropriate liquid according for the type
of marking to be carried out:
◊ INOX M, suitable for making darker, more evident
markings .
◊ INOX E, for making a clear, light marking using the
spark erosion principle.
• Pour a few drops of electrolyte solution (A) onto the
marking felt.
The felt wetted with the electrolytic solution
allows about 15 consecutive markings to be
made, after which it must be moistened again.
• Turn on the device by turning the main switch (located on
the back of the unit) to the "I" position.
• Select the desired operating mode by pressing the MODE
button on the control panel (see chapter 3.3 for more
information).
• Unlike cleaning and polishing, the marking process with
the 35 mm insert requires a minimum amount of current,
so it is not necessary to select a particular working power.
• Press the SET button to select the desired power
level (see chapter 3.4 for more information).
In order not to cause excessive wear or damage to the
accessories, it is recommended that you select the power
level according to the following table, which takes into
account both the power supplied by the x2 line device
model used, and the conductivity of the electrolyte solution.
• Press the
button on the control panel to start the device.
Once started, the appliance switches o
automatically after approximately 30 seconds
of inactivity.
This is a precautionary measure to prevent
the torch from being accidentally powered at
the end of processing.
• Repeatedly apply the wet marking felt to the logo or on the text that must be imprinted on the stainless steel surface (B).
• Stay inside the edges of the screen to avoid marking the steel outside the desired area.
• Always keep the felt well moistened with the electrolytic solution to avoid overheating and consequent
signicant reduction in its working life; if there are obvious signs of wear, replace the component immediately.
• Never use an insert without its matching felt; the insert must never be placed in direct contact with the screen.
• The device automatically supplies the appropriate voltage when the marking operating mode is selected.
Do not press the – and + buttons on the control panel to adjust the output power, otherwise a number of
problems may occur, such as:
◊ Weak and/or poorly dened markings.
◊ Burns on the marking felt.
◊ Burns on the screen-printing screen.
◊ Unwanted halos on the workpiece.
