27
line
max
15 mm
A
D
B
C
Ee
CLINOX PRO • AIR • POWER • SURFACE
USER MANUAL
4.9.
• Install the brush adapter (A) on the torch (see chapter 4.2).
• The adapter is equipped with a threaded coupling (B); x the O-ring seal (C) onto the thread.
• Screw the brush onto the threaded coupling; be careful when threading the end of the brush tube (D).
• Adjust the brush bushing (E) to ensure that no more than 15 mm of carbon bres are exposed.
