24
NITTY GRITTY.IT
make it shine
A
C
D
B
CLINOX PRO • AIR • POWER • SURFACE
USER MANUAL
4.6.
For some types of inserts, the felt is xed using a PTFE
ring. In these cases, the felt insertion tool on the back of the
device is used for assembly (refer to chapter 2.3).
• Install the insert on the torch (see chapter 4.2).
• Insert the PTFE ring (C) into the special oval slot of the
felt insertion tool (A). To do this, apply a light pressure with
your ngers to the two opposite sides of the ring so that it
takes on an elliptical shape, then position it in place.
• Place the felt (D) in the rectangular groove of the felt
insertion tool (B).
• Take the torch and push the tip on the felt insertion tool so
that the felt and the ring both t onto the electrode.
