FD 100/320Gbps NT and FX NT IHub Services Guide Virtual Private Routed Network Service
Issue: 13 3HH-11985-AAAA-TQZZA 579
Table 634 describes the command output fields for a BGP neighbor.
Table 634 Show BPG Neighbor Output
Description This command displays BGP neighbor information. This command can be entered with or
without any parameters.
When this command is issued without any parameters, information about all BGP peers
displays.
When the command is issued with a specific IP address or ASN, information regarding only
that specific peer or peers with the same AS display.
When either received-routes or advertised-routes is specified, then the routes received from or
sent to the specified peer is listed (see second output example).
Note: This information is not available by SNMP.
When either history or suppressed is specified, then the routes learned from those peers that
either have a history or are suppressed (respectively) are listed.
The ‘State’ field displays the BGP peer’s protocol state. In additional to the standard protocol
states, this field can also display the ‘Disabled’ operational state which indicates the peer is
operationally disabled and must be restarted by the operator.
Parameters ip-address — Displays the BGP neighbor with the specified IP address.
family family — Selects the address family to be shown
Values: ipv4 — Displays only those BGP peers that have the IPv4 family enable and not those
capable of exchanging IP-VPN routes.
ipv6 — Displays the BGP peers that are IPv6 capable.
filter1 — Specifies route criteria.
Values: received-routes, advertised-routes, history, suppressed, detail
filter2 — Specifies route criteria.
Values: history, suppressed, detail
Label Description
Peer The IP address of the configured BGP peer.
Group The BGP peer group to which this peer is assigned.
Peer AS The configured or inherited peer AS for the peer group.
Peer Address The configured address for the BGP peer.
Peer Port The TCP port number used on the far-end system.
Local AS The configured or inherited local AS for the peer group.
Local Address The configured or inherited local address for originating peering for the peer group.
Local Port The TCP port number used on the local system.
Peer Type External — Peer type configured as external BGP peers.
Internal — Peer type configured as internal BGP peers.
(1 of 4)
Item Description
(2 of 2)
