Table 7-14 Wireless (5GHz) parameters
Field Description
Enable Select this checkbox to enable Wi-Fi.
Bandwidth Select from:
• 20 MHz
• 40 MHz
• 80 MHz
Channel Select a channel from the list or select Auto to have the channel automatically assigned.
Transmitting Power Select a percentage for the transmitting power from the list:
• Low (25%)
• Medium (50%)
• High (75%)
• Maximum (100%)
WMM Select Enable or Disable from the list to enable or disable WiFi multimedia.
Total MAX Users Enter the total number of MAX users.
SSID Configuration
SSID Select Select the SSID from the list.
SSID Name Change the name of the selected SSID.
Enable SSID Select Enable or Disable from this list.
SSID Broadcast Select Enable or Disable SSID broadcast from this list.
Port Mode Select a port mode from the list. Route is the default.
Isolation Select Enable or Disable from this list.
MAX Users Enter the number of MAX users.
Encryption Mode Select an encryption mode from the list:
• OPEN
• WPA/WPA2 Personal
• WPA/WPA2 Enterprise
WPA Key Enter the WPA key.
Enable WPS Select Enable or Disable WPS from this list.
WPS Mode Select a WPS mode from the list: PBC (Push Button Connect) or PIN (Personal Identification Number).
Domain Grouping
Domain Grouping Select this checkbox to enable domain grouping. The fieldsDomain Name, Create One New Domain,
WAN Interface, Number of IPs and LAN List are available when the Domain Grouping field is enabled.
Domain Name Select a domain name from the list.
Create One New Domain Select this checkbox to create a new domain.
WAN Interface Select a WAN interface from the list.
Configure a G-2425G-B indoor ONT
Network configuration
Configuring Wireless 5GHz
7368 ISAM ONT
Draft Draft
August 2020
Issue 4 103
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
