A policy can only be deleted if it is not associated with any classifier rules.
5
Click Network→US Classifier from the left pane in the GPON Home Gateway page, and
select the Classifier tab.
All classifiers are displayed in the classifier table in the page.
6
Configure the following parameters:
At least one field must be selected to create a classifier. A maximum of four fields may be
selected to create a classifier; this includes the interface field.
Table 7-20 US Classifier parameters
Field Description
Interface Select an interface from the list; for example, None, LAN, 2.4G SSID, or 5G SSID.
Source MAC Click to enter a source MAC address.
Destination MAC Click to enter a destination MAC address.
Source IP Click to enter a source IP address.
Figure 7-24 US Classifier page
Configure a G-2425G-B indoor ONT
Network configuration
Configuring Upstream (US) Classifier
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
August 2020
112 Issue 4
