2
Select a tunnel interface.
Table 7-19 US Classifier Policy parameters
Field Description
Tunnel Type The tunnel type is set to GRE and cannot be modified.
Tunnel Interface Select a tunnel interface from the list: No Tunnel, GRE Tunnel, or LAN traffic.
VLAN ID Enter a VLAN ID (0-4094).
VLAN Tag This field is not configurable. The VLAN tag is set to 8100 (hexadecimal).
VLAN Priority Enter a VLAN priority level (0 to 7). A lower number indicates a higher priority.
IP TOS/DSCP This field is not configurable. All tunnel packets are generated with a default DSCP value
(usually 0).
Drop Select this checkbox to drop the packets.
3
Click Save.
4
To delete a policy, click Delete for the applicable policy in the policy table.
Figure 7-23 US Classifier Policy page
Configure a G-2425G-B indoor ONT
Network configuration
Configuring Upstream (US) Classifier
7368 ISAM ONT
Draft Draft
August 2020
Issue 4 111
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
