Table 4-9 G-2425G-B indoor ONT capacity for GEM ports and T-CONTs
ONT or MDU Maximum Notes
Package P ONTs
GEM ports per indoor or outdoor ONT 256 256 are present; 254 are available, and 2 are reserved for
multicast and debugging
T-CONTs per indoor or outdoor ONT 32 32 are present; 31 are available, and 1 is reserved for
OMCI
4.9 G-2425G-B performance monitoring statistics
The following section identifies the supported performance monitoring statistics for G-2425G-B
ONTs. A check mark indicates the statistic is supported on that ONT. An empty cell indicates the
statistic is not supported. The following tables are categorized by supported alarm types:
•
Table 4-10, “Package S ONTs ONTENET performance monitoring statistics” (p. 53) provides
statistics for ONTENET type counters
• Table 4-11, “Package S ONTs ONTL2UNI performance monitoring statistics” (p. 54) provides
statistics for ONTL2UNI type counters
• Table 4-12, “Package S ONTs PONONTTC, PONONTMCTC, PONONTTCHSI,
PONONTTCCES, PONONTTCFLOW, PONONTTCVOIP performance monitoring statistics”
(p. 54) provides statistics for PONONTTC, PONONTMCTC, PONONTTCHSI, PONONTTCCES,
PONONTTCFLOW, and PONONTTCVOIP type counters
•
Table 4-13, “Package S ONTs PONONTTC aggregate performance monitoring statistics” (p. 54)
provides statistics for PONONTTC aggregate type counters
Note: If you have trouble accessing G-2425G-B ONTs performance monitoring statistics using
TL1, please contact your Nokia support representative for more information about how to
access and retrieve performance monitoring type counters.
Table 4-10 Package S ONTs ONTENET performance monitoring statistics
ONT ONTENET statistics
FCSE EC LC RBO SCF MCF DT IMTE CSE AE IMRE FTL TBO SQE
G-2425G-B
1
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ — ✓
2
✓ —
Notes:
1. A 5 second polling window limitation exists on the ONT, therefore the margin of error for each 15-min window
is 5 seconds
2. Only packets larger than 9 kB will be counted.
