2
Configure the following parameters:
Table 7-32 Port Forwarding parameters
Field Description
Application Name Select an application name from the list.
The default is Custom settings.
WAN Port Enter the WAN port range.
LAN Port Enter the LAN port range.
Internal Client Select a connected device from the list and enter the associated IP address.
Protocol Select the port forwarding protocol from the list:
• TCP
• UDP
• TCP/UDP
Enable Mapping Select this checkbox to enable mapping.
WAN Connection List Select a WAN connection from the list.
Note: Only active devices are shown on this list.
Figure 7-35 Port Forwarding page
Configure a G-2425G-B indoor ONT
Configuring the Application
Configuring port forwarding
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
August 2020
130 Issue 4
