Nokia 7368 Intelligent Services Access Manager ONT User Manual

Table 4-5, “G-2425G-B indoor ONT LED descriptions” (p. 50) provides LED descriptions for
G-2425G-B indoor ONTs.
Table 4-5 G-2425G-B indoor ONT LED descriptions
Indicator LED color and
behavior
LED behavior description
Power Green solid
Red solid
Off
Power on
Light failed on startup (for example corrupt flash), or self test failed on startup, or self test
failed during regular operation or when executed over OMCI
Power off
Link Green solid
Off
GPON link between ONT and OLT is operating normally
GPON link is down or no link is connected
Figure 4-4 G-2425G-B indoor ONT LEDs
TEL1LINK AUTH TEL2LAN1 LAN2 LAN3 LAN4POWER WPS VOIPWLAN2.4G WLAN5G USBINTERNET
TEL1LINK AUTH TEL2LAN1 LAN2 LAN3 LAN4POWER WPS VOIP WLAN2.4G WLAN5G USBINTERNET
35958
G-2425G-B unit data sheet
G-2425G-B LEDs
7368 ISAM ONT
Draft Draft
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
August 2020
50 Issue 4
