4.7 G-2425G-B detailed specifications
Table 4-6, “G-2425G-B indoor ONT physical specifications” (p. 51) lists the physical specifications
for G-2425G-B indoor ONTs.
Table 4-6 G-2425G-B indoor ONT physical specifications
Description Specification
Length 9.6 in. (245 mm)
Width 3.14 in. (80 mm)
Height (including antenna)
(without antenna)
7.63 in. (194 mm) 5.45 in.(138.4 mm)
Weight [within ± 0.5 lb (0.23 kg)]
(net weight of ONT)
1.36 lbs (618g)
Table 4-7, “G-2425G-B indoor ONT power consumption specifications” (p. 52) lists the power
consumption specifications for G-2425G-B indoor ONT.
Table 4-7 G-2425G-B indoor ONT power consumption specifications
Mnemonic Maximum power
(Not to exceed)
Condition Minimum power Condition
G-2425G-B 36 W 1 POTS off-hook, 4 10/100/1000
Base-T Ethernet, Wi-Fi
operational, USB operational
7.2 W 1 POTS on-hook, other
interfaces/services not
provisioned
Table 4-8, “G-2425G-B indoor ONT environmental specifications” (p. 52) lists the environmental
specifications for G-2425G-B indoor ONT.
Table 4-8 G-2425G-B indoor ONT environmental specifications
Mounting method Temperature range and humidity Altitude
On desk or shelf Operating: 23°F to 113°F (-5°C to 45°C) ambient
temperature
5% to 95% relative humidity, non-condensing
Contact your Nokia technical support representative for
more information
Storage: -4°F to 158°F (-20°C to 70°C)
4.8 G-2425G-B GEM ports and T-CONTs
Table 4-9, “G-2425G-B indoor ONT capacity for GEM ports and T-CONTs” (p. 53) lists the
maximum number of supported T-CONTs and GEM ports. See the appropriate release Customer
Release Notes for the most accurate list of supported devices.
G-2425G-B unit data sheet
G-2425G-B detailed specifications
7368 ISAM ONT
Draft Draft
Nokia Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
August 2020
52 Issue 4
