Nokia 7368 Intelligent Services Access Manager ONT - Figure 4-3 G-2425 G-B Indoor ONT with Fiber Optic Connector

Figure 4-3, “G-2425G-B indoor ONT with fiber optic connector” (p. 48) shows the G-2425G-B
indoor ONT with a fiber optic connector.
Figure 4-2 G-2425G-B indoor ONT physical connections (back)
ON/OFF RESET WLAN
POWER
LAN4LAN3LAN2LAN1TEL2TEL1
USB1 USB2
LEDWPS
35955
Figure 4-3 G-2425G-B indoor ONT with fiber optic connector
ON/OFF RESET WLAN
POWER
LAN4LAN3LAN2LAN1TEL2TEL1
USB1 USB2
LEDWPS
35956
