Table 7-20 US Classifier parameters (continued)
Field Description
Destination IP Click to enter a destination IP address.
Source Port Click to enter a source port.
Destination Port Click to enter a destination port.
Protocol Click to enter a protocol.
Priority Select a priority level from 1 to 8. The lower the number, the higher the priority. No more
than 1 classifier can be created with the same priority.
7
Click Save.
8
To delete a classifier, click Delete for the applicable classifier in the classifier table.
A classifier can only be deleted if it is not associated with any classifier rules.
9
Select the Classifier Rules tab.
All classifier rules are displayed in the classifier rules table in the page.
Figure 7-25 US Classifier Rules page
Configure a G-2425G-B indoor ONT
Network configuration
Configuring Upstream (US) Classifier
7368 ISAM ONT
Draft Draft
August 2020
Issue 4 113
Nokia – Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
