Table 7-4 WAN Status IPv6 parameters
Field Description
WAN Connection List Drop-down menu listing all WAN connections. The connection shown is the connection for which WAN
status will be shown.
Enable/Disable Select this checkbox to enable the WAN connection
VLAN VLAN ID
WAN Link Status Whether the WAN link is up or down
IPv6 Address IPv6 address that identifies the device and its location
IPv6 Prefix IPv6 prefix
IPv6 Gateway IPv6 gateway address
Primary DNS Primary Domain Name Server
Second DNS Secondary Domain Name Server
PON Link Status Whether the PON link is up or down
Figure 7-5 WAN Status IPv6 page
Configure a G-2425G-B indoor ONT
Viewing device information and connection status
Viewing WAN IPv6 status
