You can:
Click Delete to delete a particular local device connection.
Click Refresh to display up-to-date information.
END OF STEPS
7.11 Viewing optics module status
1
Click Status→Optics Module Status from the left pane in the GPON Home Gateway page.
The Optics Module Status page displays.
Table 7-6 Optics Module Status parameters
Field Description
Laser Bias Current (ONT ANI-ONT-Side Optical Measurements) Laser bias current, measured in uA
Optics Module Voltage (ONT ANI-ONT-Side Optical Measurements) Optics module voltage, measured in V
Optics Module Temperature (ONT ANI-ONT-Side Optical Measurements) Optics module temperature, measured in C
Rx Optics Signal Level at 1490 nm (ONT ANI-ONT-Side Optical
Measurements)
Received optics signal level at 1490 nm, measured in
dBm
Tx Optics Signal Level at 1310 nm (ONT ANI-ONT-Side Optical
Measurements)
Transmitted optics signal level at 1310 nm, measured in
dBm
Lower (ONT ANI-ONT-Side Optical Measurements-Optical Threshold) Lower optical threshold, measured in dBm
Figure 7-7 Optics Module Status page
Configure a G-2425G-B indoor ONT
Viewing device information and connection status
Viewing optics module status
7368 ISAM ONT
Draft Draft
August 2020
Issue 4 85
Nokia Proprietary and Confidential
Use pursuant to applicable agreements
3FE-48293-ACAA-TCZZA
