Nokia N72

Min Typ Max
PL15 coefficient 0.12 0.194 0.3
GSM1900 EDGE off
PL0 coefficient 0.45 0.482 0.7
PL11 coefficient 0.218
PL15 coefficient 0.12 0.184 0.3
GSM1900 EDGE on
PL2 coefficient 0.35 0.377 0.6
PL11 coefficient 0.23
PL15 coefficient 0.12 0.193 0.3
8. If the values are within the limits, click Next to proceed to the next band, and click Start.
9. Set Edge mode on and start tuning again. Change video averaging to 50.
10. Tune EDGE power levels to the corresponding target power levels.
Only power levels 8, 15 and 19 are tuned in GSM900, and 2, 10 and 15 in GSM1800/1900.
11. When the tuning is completed, close the Tx Power Level Tuning window.
RM-180
Nokia Customer Care RF Troubleshooting and Tuning Guide
Page 7 –34 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
