Nokia N72

ITEM/ CIRCUIT
REF.
QTY PART NAME
I029 1 IHF TOP PAD
I030 1 SLIDE DETECT LEVER
I031 1 SIM FLAP
I032 1 BT ANTENNA ASSY
I033 1 IHF COVER ASSY
I034 1 LED FLASH
I035 1 CAMERA REAR BEZEL ASSY
I036 1 CAMERA REAR BEZEL ADHESIVE
1 ANTENNA ASSY
I037 1 ANTENNA RADIATOR GSM
I039 1 ANTENNA MODULE
I040 1 TYPE LABEL
I041 1 ANTENNA COVER
I042 1 POWER BUTTON
I043 1 BATTERY COVER
Component parts list (1YA_02.1f)
Item Side Grid ref. Type Description and value
A7003 Bot D 10
SHIELD_ROLF_R
F
SHIELD ASSEMBLY
HINKU/VINKU
040-010018 ~ ~
A7004 Bot B 7
SHIELD_ROLF_V
CO SHIELD ROLF VCO ~ ~
A7005 Bot E 12
SHIELD_ROLF_F
LASH
SHIELD ROLF GSM
FLASH ~ ~
A7006 Bot D 6
SHIELD_ROLF_T
AHVO SHIELD ROLF TAHVO ~ ~
A7008 Bot H 17
SHIELD_ROLF_
GSM_PA SHIELD ROLF GSM PA ~ ~
B2200 Top D 6
CRYSTAL_3.3X1
.6_H0.9
CRYSTAL 32.768KHZ
+-20PPM 12.5PF
32.768kH
z ~
C1470 Bot D 15 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C1471 Bot F 18 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C1472 Bot F 6 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
