Nokia N72

RF testing and BB testing/tuning
Figure 36 RF testing and BB testing/tuning
Item Type Description
1 FS-14 + SS-62 Flash adapter + generic flash
adapter base for BB5 products
2 CU-4 Control unit
3 SA-95 RF coupler
4 PCS-1 Power cable
5 Standard USB cable
6 Standard USB cable + smart card
reader
7 SX-4 Smart card
8 GPIB control cable
9 XRF-1 RF cable
10 PKD-1 SW security device
11 RF shield box
Note: Item 11 not shown in the picture.
RM-180
