Nokia N72

Parts lists
Mechanical spare parts list
Note: For Nokia product codes, please refer to the latest Service Bulletins on the Partner Website (PWS).
To ensure you are always using the latest codes, please check the PWS on a daily basis.
Bold = ASSY
ITEM/ CIRCUIT
REF.
QTY PART NAME
I001 1 A COVER ASSY
I002 1 MMC DOOR
I003 1 KEYMAT
I004 6 SCREW RF 1.8X9
1 UI FRAME ASSY
I005 1 UI FRAME
I006 1 BEZEL GROUND SPRING
I007 4 LCD GROUND PIN
I008 1 EARPIECE
I009 1 EARPIECE ADHESIVE
1 1NC UI PWB ASSY
I010 1 UI PWB
I011 1 SWITCH
I012 1 DOMESHEET
I013 1 BB SHIELD ASSEMBLY
I014 1 LCD AM 176X208
I017 1 ENGINE MODULE
I018 1 GSM PA SHIELDING LID
I020 1 TAHVO SHIELDING LID
I021 1 HINKU / VINKU SHIELDING LID
I022 1 FLASH SHIELDING LID ASSY
I023 1 CAMERA MODULE 2MP
1 CHASSIS ASSY
I024 1 CHASSIS
I025 1 DC JACK 2mm
I026 1 MICROPHONE
I027 1 VIBRA MOTOR
I028 1 IHF SPEAKER
RM-180
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –7
Copyright © 2006 Nokia. All rights reserved.
