Nokia N72

CU-4 flash concept with FPS-10
Figure 35 CU-4 flash concept with FPS-10
Note: FPS-8 concept can also be used for flashing.
Item Type Description
1 FS-14 + SS-62 Flash adapter + generic flash
adapter base for BB5 products
2 CU-4 Control unit
3 XCS-4 Modular cable
4 PCS-1 Power cable
5 FPS-10 Flash prommer box
6 Standard USB cable
7 Standard USB cable
8 PKD-1 SW security device
RM-180
