Nokia N72

Item Side Grid ref. Type Description and value
C1473 Bot G 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C1479 Bot E 14 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C1480 Bot D 14 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C1481 Top D 20 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C1482 Top D 20 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C1483 Top E 6 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C1484 Bot E 12 0805C
CHIPCAP X5R 4U7 K 6V3
0805 4u7 6V3
C1485 Bot E 13 1206C_TDK
CHIPCAP 2U2 K 25V
1206 2u2 25V
C1486 Bot E 13 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
C1487 Bot C 15 0402C Chipcap 5% NP0 10p 50V
C1488 Bot C 15 0402C Chipcap 5% NP0 10p 50V
C1489 Top E 19 0402C Chipcap 5% NP0 22p 50V
C1490 Top E 20 0402C Chipcap 5% NP0 22p 50V
C1491 Top D 19 0402C Chipcap 5% NP0 22p 50V
C2000 Bot C 3 0402C Chipcap 5% NP0 27p 50V
C2002 Bot F 3 0603C
CHIPCAP X5R 2U2 K 6V3
0603 2u2 6V3
C2003 Bot F 3 0402C
CERCAP X7R 22N K 16V
0402 22n 16V
C2004 Bot G 3 0402C
CERCAP X7R 22N K 16V
0402 22n 16V
C2005 Bot F 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2006 Bot G 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2007 Bot G 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2008 Bot G 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2009 Bot G 2 0402C
Chipcap X7R 10% 16V
0402 10n 16V
RM-180
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –9
Copyright © 2006 Nokia. All rights reserved.
