Nokia N72

Item Side Grid ref. Type Description and value
C2010 Bot G 3 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2011 Top F 1 0402C
CHIPCAP NP0 270P J
25V 0402 270p 25V
C2012 Bot C 3 0603C_H0.95
CHIPCAP X5R 1U K 25V
0603 1u0 25V
C2070 Bot G 14 0402C Chipcap 5% NP0 15p 50V
C2072 Bot I 15 0402C Chipcap 5% NP0 15p 50V
C2100 Bot F 2 0402C
CHIPCAP X7R 15N K
16V 0402 15n 16V
C2101 Bot F 2 0402C
CHIPCAP X7R 15N K
16V 0402 15n 16V
C2102 Bot F 2 0603C
CHIPCAP X5R 2U2 K 6V3
0603 2u2 6V3
C2103 Top E 6 0402C Chipcap 5% X7R 1n0 50V
C2104 Top E 6 0402C Chipcap 5% X7R 1n0 50V
C2105 Top A 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2106 Top A 6 0402C Chipcap 5% NP0 27p 50V
C2107 Top A 6 0402C Chipcap 5% NP0 27p 50V
C2108 Top B 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2109 Top B 7 0402C Chipcap 5% NP0 27p 50V
C2110 Top A 7 0402C Chipcap 5% NP0 27p 50V
C2200 Top C 5 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2201 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2202 Top D 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2203 Top D 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2204 Top E 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2205 Top D 5 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2206 Top D 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2207 Top E 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
RM-180
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –10 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.
