Nokia N72

Item Side Grid ref. Type Description and value
C2208 Top D 7 0402C Chipcap 5% NP0 27p 50V
C2209 Top D 7 0402C Chipcap 5% NP0 22p 50V
C2210 Top B 7 0603C
CHIPCAP X5R 1U K 16V
0603 1u0 16V
C2211 Top B 6 0805C
CHIPCAP X5R 4U7 K 10V
0805 4u7 10V
C2212 Top B 6 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2213 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2214 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2215 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2216 Top D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2217 Top D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2219 Top D 6 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2220 Top B 6 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2221 Top B 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2222 Top B 6 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2223 Top C 5 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2224 Top D 5 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2225 Top D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2226 Top D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2227 Top B 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2228 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2230 Top D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
RM-180
Parts Lists and Component Layouts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 2 –11
Copyright © 2006 Nokia. All rights reserved.
