Nokia N72

Item Side Grid ref. Type Description and value
C2231 Top A 5 0805C
CHIPCAP X5R 10U M
6V3 0805 10U 6V3
C2232 Top C 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2234 Top D 6 0402C Chipcap 5% NP0 27p 50V
C2235 Top D 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2237 Top E 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2240 Top B 2 0402C Chipcap 5% NP0 12p 50V
C2241 Top G 3 0402C Chipcap 5% NP0 12p 50V
C2242 Top E 5 0402C Chipcap 5% NP0 12p 50V
C2243 Top I 3 0402C Chipcap 5% NP0 12p 50V
C2244 Top G 1 0402C Chipcap 5% NP0 12p 50V
C2300 Bot D 5 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2301 Bot D 6 0805C
CHIPCAP X5R 22U M
6V3 0805 22u 6V3
C2302 Bot D 5 0805C
CHIPCAP X5R 22U M
6V3 0805 22u 6V3
C2303 Bot D 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2304 Bot C 6 0402C
Chipcap X7R 10% 16V
0402 10n 16V
C2307 Bot E 7 0603C
CHIPCAP X5R 2U2 K 6V3
0603 2u2 6V3
C2309 Bot E 5 0805C
CHIPCAP X5R 22U M
6V3 0805 22u 6V3
C2312 Bot E 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2313 Bot E 7 0603C
CHIPCAP X5R 1U K 6V3
0603 1u0 6.3V
C2314 Top G 7 0805C
CHIPCAP X5R 4U7 M
25V 0805 4u7 25V
C2315 Top G 6 0805C
CHIPCAP X5R 4U7 M
25V 0805 4u7 25V
C2316 Bot C 6 0402C
Chipcap X7R 10% 50V
0402 1n0 50V
C2700 Bot H 7 0402C_H0.6
CHIPCAP X5R 100N M
16V 0402 100n 16V
