Norcold 2118 - Specifications

SERVICE MANUAL
5
www.norcold.com
Rough Opening Dimensions
(H x W x D) ---------------------------------------------------------------------------------------68.94 - 69.06 in. x 35.94 - 36.04 x 24.00 - 24.13 in.
Internal Capacities
Total capacity ----------------------------------------------------------------------------------------------------------------------------------------18.18 cu. ft.
Freezer ------------------------------------------------------------------------------------------------------------------------------------------------- 5.92 cu. ft.
Fresh food compartment --------------------------------------------------------------------------------------------------------------------------12.57 cu. ft.
Controls
Type ------------------------------------------------------------------------------------------------------------------ Electronic with built-in self diagnostic
ON/OFF, MODE, TEMP SET switches -------------------------------------------------------------------- LCD assembly with ush push buttons
Temperature setting range ------------------------------------------------------------------------------------------------- 1 = cold through 9 = coldest
Temperature / defrost sensing services ------------------------------------------------------------------------------------------------------ Thermistors
Fresh food thermistor ------------------------------------------------------------------------------------------------- Located on 2nd n from the right
Fans thermistor --------------------------------------------------------------------------- Located at rear of refrigerator on left most condenser n
DC Power
Electronic controls voltage requirement ----------------------------------------------------------------------------------------------- 10.5 to 15.4 VDC
Fuse-power board ------------------------------------------------------------------------------------------------ Automotive Blade, Type APR-5A-Tan
DC Current Draw at nominal 12 VDC
Fresh food blower ----------------------------------------------------------------------------------------------------------------------------- 0.200 - 0.300 A
Freezer blower---------------------------------------------------------------------------------------------------------------------------------- 0.140 - 0.185 A
Divider heater -------------------------------------------------------------------------------------------------------------------------------------------- 0.275 A*
Flapper heater -------------------------------------------------------------------------------------------------------------------------------------------0.417 A*
Perimeter heater ----------------------------------------------------------------------------------------------------------------------------------------0.275 A*
Interior light ----------------------------------------------------------------------------------------------------------------------------------------------- 0.500 A*
Gas valve -------------------------------------------------------------------------------------------------------------------------------------------------0.146 A*
External ventilation fans (2 at condenser) ---------------------------------------------- 0.430 A @ 12VDC - 2/29/2016 and before (per fan)*
---------------------------------------------------------------------------------------------------------- 0.277@ 12VDC - 3/1/2016 and after (per fan)*
External ventilation fan (1 at absorber) ------------------------------------------------------------------------------------------------------------0.140 A*
Ice maker water line heater (IM models only) ---------------------------------------------------------------------------------------------------0.167 A*
Ice maker water line heater (IMD models only) -------------------------------------------------------------------------------------------------1.250 A*
Dispenser water line heater (IMD models only) -------------------------------------------------------------------------------------------------0.167 A*
Dispenser water valve heater (IMD models only) ----------------------------------------------------------------------------------------------0.458 A*
AC power
AC input voltage requirements ------------------------------------------------------------------------------------------------------------ 108 to 132 VAC
Fuse-power board ------------------------------------------------------------------AGC Series, 8A, Fast Acting, Glass Tube (1/4 in. x 1-1/4 in.)
AC Current Draw
AC heaters (2) -------------------------------------------------------------------------------------------------------------------- 300 W, 2.5 A (per heater)
AC heater resistance -------------------------------------------------------------------------------------------------------46.0 Ω to 51.0 Ω (per heater)
Ice maker (IM models only) --------------------------------------------------------------------------------------------------------------180W at 115 VAC
Ice maker water valve (IM models only) ---------------------------------------------------------------------------------------------------------0.210 A**
Ice maker water valve (IMD models only) -------------------------------------------------------------------------------------------------------0.145 A**
Propane gas
Operating pressure ----------------------------------------------------------------------------------------------------------------------10.5 - 11.5 inch w.c.
Burner rating (8-slot burner / LP22 orice) -------------------------------------------------------------------------------- 3000 Btu/h at 11 inch w.c.
Burner orice size ------------------------------------------------------------------------------------------------------------------------------------------ LP22
Flame sensing ------------------------------------------------------------------------------------------------Electronic through spark sense electrode
Electrode tip-to-burner gap ------------------------------------------------------------------------------------------------------------------1/8 to 3/16 inch
Off-level operating limits
Side-to-side-------------------------------------------------------------------------------------------------------------------------------3 degrees-maximum
Front-to-back -----------------------------------------------------------------------------------------------------------------------------6 degrees-maximum
* = Calculated, ** = Actual
Specications
