Nordson Asymtek X-1010 User Manual

Training Guide Course No. 196514
Level 2 Maintenance, X-1000 Series Dispensing Systems 4-111 P/N 196515 (Revision A)
Observe the four power status
LEDs in the upper middle section
of the Conveyor Interface PWA.
Go to Main Power Fault
Isolation Procedure
Conveyor Controller
(P/N 62-1677-00 on
X1020, and P/N 62-1676-
00 on X1010) has failed
A
Is the fuse open?
Exit FmNT, shut down Windows
NT, press the black OFF (0)
button on Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Inspect the fuse on the Conveyor
Controller power supply.
Are all the LEDs
illuminated?
Replace fuse
Disconnect Conveyor AC Power
Cable from Conveyor Controller.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on Operator’s
Console, and enter FmNT.
Measure VAC from Conveyor
AC Power Cable.
Is reading 208
to 240 VAC (should
equal specified facility
supply voltage)?
Conveyor Controller
(P/N 62-1677-00 on
X1020, and P/N 62-1676-
00 on X1010) has failed
Yes
No
Yes No
Yes No
Observe the four power status
LEDs in the upper middle section
of the Conveyor Interface PWA.
Go to Main Power Fault
Isolation Procedure
Conveyor Controller
(P/N 62-1677-00 on
X1020, and P/N 62-1676-
00 on X1010) has failed
A
Is the fuse open?Is the fuse open?
Exit FmNT, shut down Windows
NT, press the black OFF (0)
button on Operator’s Console,
switch Main Circuit Breaker to
OFF (0), and disconnect Power
Cable from facility outlet.
Inspect the fuse on the Conveyor
Controller power supply.
Are all the LEDs
illuminated?
Are all the LEDs
illuminated?
Replace fuse
Disconnect Conveyor AC Power
Cable from Conveyor Controller.
Connect Power Cable to facility
outlet, switch Main Circuit
Breaker to ON (I), press green
ON (I) button on Operator’s
Console, and enter FmNT.
Measure VAC from Conveyor
AC Power Cable.
Is reading 208
to 240 VAC (should
equal specified facility
supply voltage)?
Is reading 208
to 240 VAC (should
equal specified facility
supply voltage)?
Conveyor Controller
(P/N 62-1677-00 on
X1020, and P/N 62-1676-
00 on X1010) has failed
Yes
No
Yes No
Yes No
Diagram Sheet 4-8-12
Heater Fault Isolation Procedure – Heater Verification (Continued)
