Description
2-2
Part 1602221-01
E 2012 Nordson Corporation
Specifications
Model Input Rating Output Rating
ENCORE Applicator +/− 19 VAC, 1 A 100 KV, 100 μA
ENCORE Controller 100−250 VAC, 50/60 Hz N/A
S Input Air: 4.0−7.6 bar (58−110 psi), <5μ particulates, dew point <10 _C
(50 _F)
S Max Relative Humidity: 95% non-Condensing
S Ambient Temperature Rating: +15 to +40 _C (59−104 _F)
S Dust Ingress Protection: IP6X
This applicator and controller are used with Porcelain Enamel powders
which are non-flammable.
Powder Spray Gun Label
NOTE: The gun serial number contains the location, year, and month it was
manufactured. The serial number starts with “AA10A”. The “AA” means the
product was built in Amherst, Ohio, the “10” meaning the year 2010. The “A”
means the month of January, “B” would be February, and so on.
Controller Certification Label
EN 50050 FM11ATEX0057X
ENCORE LT
Ex tc IIIC T60°C Dc
(2) 3 D
T = +15 to +40°C
A
NORDSON CORP. AMHERST, OH, USA
Vn=100−250Vac 7n=50−60Hz Pn=100VA
OUTPUT: V
(peak)= +19V Io(peak)= +1.0A
WARNING − POTENTIAL ELECTROSTATIC CHARGING
HAZARD, SEE INSTRUCTION MANUAL.
