Nordson Encore User Manual

Parts
7-11
Part 1602221-01
E 2012 Nordson Corporation
System Components and Parts
Item Part Description Quantity Note
NS 1602269 ASSEMBLY, pickup tube, Encore PE 1
NS 1107552 CONTROLLER, manual, Encore LT, packaged 1
NS 1602268
PUMP assembly, 90_, Encore PE
1
NS 1107913 KIT, rail mount, Encore LT 1
NS 1067694 KIT, ground bus bar, ESD, 6 position, w/hardware 1
NS 1600658 HANGER, gun, Encore LT 1
NS 1600566 KIT, filter, Encore LT 1 A
NS 1600608
S FILTER, mist separator, 0.3 micron, 1/2 in. NPT
1
NS 1600609
SS FILTER ELEMENT, separator, 0.3 micron
1
NOTE A: Filter kit includes fittings and mounting bracket.
NS: Not Shown
Powder Hose and Air Tubing
Powder hose and air tubing must be ordered in increments of one foot.
Part Description Note
900724 Tubing, powder, polyurethane, 0.500 in.
900617 Air tubing, polyurethane, 4 mm, clear A
900742 Air tubing, polyurethane, 6 mm, blue A
1096789 Air tubing, antistatic, 6/4 mm, black (conductive air tubing)
900741 Air tubing, polyurethane, 6 mm, black
900618 Air tubing, polyurethane, 8 mm, blue A
900619 Air tubing, polyurethane, 8 mm, black A
900740 Air tubing, polyurethane, 10 mm, blue A
900517 Tubing, poly, spiral cut, 0.62 in. ID
301841 Strap, Velcro, w/buckle, 25 x 3 cm
NOTE A: Minimum order quantity is 50 ft.
System Options
Part Description Quantity Note
1091429 KIT, input air, Encore manual systems 1
972841
S CONNECTOR, male, 10 mm tube x
1
/
4
in. unithread
1
971102
S CONNECTOR, male, 10 mm tube x
3
/
8
in. unithread
1
973500
S COUPLING, pipe, hydraulic,
1
/
4
in., steel, zinc
1
973520
S COUPLING, pipe, hydraulic,
3
/
8
in., steel, zinc
1
900740
S TUBING, polyurethane, 10 mm, blue
20 ft A
NOTE A: Replacement tubing has a minimum order quantity of 50 ft.
