Nordson Encore User Manual

Parts
7-7
Part 1602221-01
E 2012 Nordson Corporation
Front Panel and Internal Cabinet Ground Parts List
Refer to Figure 7-3.
Item Part Description Quantity Note
− 1107552 CONTROLLER ASSY, manual, Encore LT,
packaged
1
1 1108279
S KIT, PCA, control, Encore LT
1
2 1108312
S PANEL, keypad, Encore LT/auto controller,
packaged
1
3 982916
S SCREW, flat, socket, M5 x 10, black
4
4 982636
S SCREW, button, socket, M5 x 12, zinc
2
5 983127
S WASHER, lock, internal, M5, zinc
2
6 983403
S WASHER, lock, split, M4, steel, zinc
4
7 982881
S SCREW, pan head, recessed, M4 x 6, zinc
2
8 1045837
S SCREW, pan head, recessed, M5 x 12
w/lockwasher, black
2
9 984702
S NUT, hex, M5, brass
1
10 983401
S WASHER, lock, split, M5, steel, zinc
1
11 983021
S WASHER, flat, 0.203 x 0,406 x 0.040, brass
1
12 933469
S LUG, 90, double, 0.250, 0.438 in.
1
13 240674
S TAG, ground
1
