Part 1602221-01
E 2012 Nordson Corporation
Rear Panel Parts List
Refer to Figure 7-4.
Item Part Description Quantity Note
14 984526
S NUT, lock, 1/2 in. conduit
1 A
15 939122
S SEAL, conduit fitting, 1/2 in., blue
1
16 1107539
S RECEPTACLE, gun, Encore LT
1
17 1045837
S SCREW, pan head, recessed, M5 x 12, with
lockwasher, black
4
18 1068715
S WASHER, lock, dished, #10
1
19 972930
S PLUG, push in, 8 mm tubing, plastic
1
20 972808
S CONNECTOR, strain relief, 1/2 in. NPT
2
21 984192
S NUT, lock, 1/2 in. NPT, nylon
2
22 117549
S GASKET, panel, rear, Encore LT controller
1
23 982824
S SCREW, pan head, recessed, M3 x 8, with
lockwasher, black
10
24 1107696
S FILTER, line, RFI power, 3A, with 0.250 QD
1
25 1108310
S KIT, PCA, relay board, Encore LT
1
26 1107695
S POWER SUPPLY, 24VDC, 60W
1
