Parts
7-5
Part 1602221-01
E 2012 Nordson Corporation
Spray Gun Options
Miscellaneous Spray Gun Options
See Figure 7-1.
Item Part Description Quantity Note
NS 1085168 CABLE, 6 meter extension, shielded, Encore
manual
1
NS: Not Shown
Optional Flat and Corner Spray Nozzles
Spray guns are shipped with a conical nozzle. If replacing the conical
nozzle with an optional flat or corner spray nozzle, order a new nozzle nut
and flat spray electrode holder kit along with a nozzle.
1601744
6 mm Flat Spray Nozzle
1601745
4 mm Flat Spray Nozzle
1601748
6 mm Corner Spray Nozzle
1601749
4 mm Corner Spray Nozzle
1601431
Nozzle Nut
1602194
Flat Spray Electrode Holder Kit
Wear Sleeve
Electrode Holder
Electrode
Figure 7-2 Optional Flat and Corner Spray Nozzles
