Nordson Encore User Manual

Parts
7-3
Part 1602221-01
E 2012 Nordson Corporation
See Figure 7-1.
Item Part Description Quantity Note
− 1601416 SPRAY GUN, manual, Encore PE 1
1 1601811
S RETAINER, deflector, 38 mm, Encore PE
1
2 245523
S DEFLECTOR, 38 mm diameter, ceramic
1
3 945016
SS O-RING, silicone, 0.251 x 0.40 x 0.074 in.
1
4 246578
S INSERT, Pyrex
1
5 940331
S O-RING, silicone, 2.00 x 2.175 x 0.063 in.
1
6 942240
S O-RING, hotpaint, 1.75 x 2.00 x 0.125 in.
1
7 982455
S SCREW, SET, M6 x 1.0 x 8, nylon, black
1
8 1601433
S SLEEVE, pattern adjuster, Encore PE
1
9 1602039
S O-RING, Buna-N, 46 x 3, 70 duro
1
10 1601430
S NOZZLE, conical, Encore PE
1
11 1601431
S NUT, nozzle, Encore PE
1
12 1601422
S RING, retaining, nozzle, Encore PE
1
13 1601814
S HOLDER, electrode, conical, Encore PE
1
14 1602041
S ELECTRODE, spring contact, Encore PE
1
15 1601423
S SUPPORT assembly, electrode, Encore PE
1
16 1601428
SS SPIDER, ceramic, Encore PE
1
17 1602193
SS KIT, sleeve, Encore PE
1
18 1601429
SSS SPRING, compression, 0.088 x 0.75 long
1
19 1602192
SS KIT, electrode support, Encore PE
1
20 1088506
S KIT, body assembly, handgun, Encore
1
20A 1088558
SS FILTER assembly, handgun
1
21 1084821
S POWER SUPPLY, 100 kV, Encore, packaged
1
22 1601437
S ELBOW assembly, spray gun, Encore PE
1
22A 940163
SS O-RING, silicone, 0.625 x 0.75 x 0.063 in.
1
23 1088502
S GASKET, multiplier cover, handgun, Encore
1
24 1106872
S BULKHEAD, multiplier, handgun, Encore LT/XT
1
25 982427
S MACHINE SCREW, panhead, M3 x 6, zinc
1
26 983520
S WASHER, lock, internal, M3, steel, zinc
1
27 1106871
S HANDLE, ground pad, handgun, Encore LT/XT
1
28 1087559
S COVER, gun display housing, Encore
1
29 1087558
S HOUSING, gun display, Encore
1
30 1087760
S HOOK, handgun, Encore
1
31A 1078075
S SCREW, Phillips head, M3 x 30, zinc plate
1
31B 760580
S SCREW, Phillips head, M3 x 20, zinc plate
3
32 1081777
S RETAINING RING, external, 10 mm, E-ring
1
33 1106756
S CABLE assembly, handgun, Encore LT/XT, 6
meter
1
33A 940129
SS O-RING, silicone, conductive, 0.375 x 0.50in.
1
34 1108095
S KIT, trigger switch, Encore
1
34A 1106875
SS AXLE, trigger, handgun, Encore LT/XT
1
Continued...
