Nordson FP-200 User Manual

Parts
8-14
Part 237478_03
E 2012 Nordson Corporation
H‐200 Adjustable Module
Item Part Description Quantity Note
- 1048115 Service kit, Module, ClassicBlue Ref
1 986 502 Ring, Retaining, Int., 43, Pushon 1
2 1106746
Body, Module, ClassicBlue
1
3 983 012 Disk, Seal Support, 0.100 X 0.442 X 0.130 2
4 276 229 Seal, Hat, Formed 2
5
1071968
Seal, Spring, 0.100 X 0.442 X 0.130 1
6 940 090 O‐ring, Viton, 0.208ID X 0.070W, BR, 10409 2
7 - Not Used -
8 - Not Used -
9 1051134 Screw, Fillister Head, 6‐32 x0.52, W/Lk Washer 2
10 1051132 Screw, Spring Loading, ClassicBlue 1
11 272 289 Nut, Locking,
1
/
2
‐ 28 in. 1
12 987 022 Spring, Comp, 1.146 in. x 0.360 in. x 0.065 in. 1
13 1051133
Air Cap, Adjuster, H200/ClassicBlue
1
14 150 170
Needle w/Piston, H200
1
15 - Not Used -
16 - Not Used -
17 - Not Used -
18 1016230 Seat, w/Carbide, H200, Lapped 1
19 981 572 Screw, Oval, 8‐32 x 0.375, SL, ZN 4
20 982 871 Screw, Socket, Cap, 10‐32 W/O Ring 2
21 - This Item number is reserved -
22 1120201 Lubricant, O-Ring, NSF-H1, 10 ML Tube -
23 144 892 Spring, Compression, 0.420 in. x 0.500 1
