Nordson FP-200 User Manual

Parts
8-10
Part 237478_03
E 2012 Nordson Corporation
FP‐200 Extrusion Gun (Front View, Air Valve, Wiring and
RTD)
Item Part Description Quantity Note
– 234 897 Gun, FP‐200, Extrusion 1
1 981 515 S Screw, Socket, 8‐32 x 0.437 in. 2
2 983 011 S Washer, Lock, Internal, 8 6
3 234 875 S Plate, Mounting, Gun, FP‐200 1
4 222 876 S Handle, Gun, FP‐200 (Auxiliary Guide Handle) 1
5 220 643 S Connector, Male, 0.125 in. x 0.125 in 1
6 1108372 S Lubricant, O-Ring, NSF-H1, Food Grade –
7 985 101 S Rivet, Pop, 3‐32 x 0.125, Aluminum 2
8 234 893 S Tag, Caution, Surface Temperature, FP‐200 1
9 332 421 S Spring, 0.21 in. x 0.50 in. 1
10 981 536 S Screw, Button, Socket, 6‐32 x 0.375 in. 2
11 332 419 S Guide, Puller, FP‐200 1
12 271 626 S Plate, Bearing 1
13 234 869 S Washer, 0.437 in. x 0.113 in. x 0.063 in. 1
14 982 804 S Hex Nut, Lock, 4‐40 1
15 332 420 S Puller, FP‐200 1
16 234 884 S Valve, Cartridge, 3‐Way (Air Valve) 1
17 986 503 S Retaining Ring, Internal, 37, Push‐on 1
18 234 867 S Body, Valve, Air, FP‐200 1
19 272 720 S Mounting Block, RTD, H‐20 1
20 981 005 S Screw, Round, 5‐40 x 0.437 in., Slotted 2
21 939 586 S Connector, Plastic, 2 Station (Terminal Block) 1
22 972 862 S Eyelet, 0.065/0.075 in. x 0.187 in. 2
23 983 505 S Washer, Lock, Split, 5 1
24 981 000 S Screw, Fillister, 5‐40 x 0.250 in., Slotted 1
25 938 129 S Heater, Cartridge, 0.375 in., 1.00 in., 80W,
240V
2
