Nordson FP-200 User Manual

Parts
8-8
Part 237478_03
E 2012 Nordson Corporation
FP‐200 Extrusion Gun (Side and Top Views)
Item Part Description Quantity Note
– 234 897 Gun, FP‐200, Extrusion 1
NS 234 970 S Heatshield, Gun, FP‐200, Extrusion 1
NS 276 644 S Clamp, Hose, 1.6 in. x 1.874 in. 12
NS 900 509 S Tubing, Polyethylene, 0.250 in. x 0.040 in., 50 ft. 1
1 169 725 S Swivel, Ball, Multi‐Plane,
5
/
16
in. 1
2 344 896 S Elbow, Male,
1
/
4
in. x 10‐32 1
3 981 735 S Screw, Fillister, 6‐32 x 0.50 in. with Poly‐Lok 4
4 971 607 S Connector, 10‐32 x
1
/
4
in. 1
5 220 648 S Tube, Air Supply, FP‐200 (High‐Temperature) 1
6 971 618 S Union, Tube,
1
/
4
in., Brass 1
7 981 083 S Screw, Pan, 8‐32 x 0.250 in., Slotted 2
8 983 011 S Washer, Lock, Internal, 8, 2
9 234 883 S Bracket, Mounting 1
10 971 605 S Elbow, Universal (Extrusion Air Line) 1
11 234 858 S Fitting, Hose, Barb, Swivel 1
12 234 889 S Trigger, Gun, FP‐200 1
13 985 216 S Pin, Dowel, 0.250 in. x 1.250 in. 1
14 271 620 S Spring, Wave, Safety 1
15 234 888 S Shell, Handgun, Left, FP‐200 1
16 234 887 S Shell, Handgun, Right, FP‐200 1
17 982 743 S Screw, Socket, 8‐32 x 1.375 in. 2
18 101 887 S Clamp, Tube, 0.228 in. 1
19 234 870 S Spacer, FP‐200 2
20 157 215 S Insulator, Mount, FP‐200 1
21 234 879 S Tube, Module, FP‐200 1
22 1108372 S Lubricant, O-ring, NSF-H1, Food Grade –
23 973 402 S Plug, Pipe, Socket, Flush,
1
/
8
in. (opposite side) 2
24 1052938 S Module,SoildBlue S 1 A
25 973 403 S Plug, Pipe, Socket, Flush,
1
/
16
in. 1
26 981 055 S Screw, Pan, 8‐32 x 0.250 in., Slotted 6
27 178 475 S Tag, Surface 1
28 157 205 S Body, Gun, FP‐200 (Service Block) 1
29 220 645 S Hose, Module, FP‐200 1
30 174 881 S Cordset Assembly, FP‐200, with Eyelets 1
31 174 885 S Adhesive, Threadlocking –
32 971 605 S Elbow, Universal (Inlet Air Line) 1
33 972 623 S Fitting, Barbed, Elbow,
1
/
4
in. x
1
/
8
in. 1
Continued on next page
