Page #22 background imageLoading...
Page #22 background image
Description
2-6
Part 237478_03
E 2012 Nordson Corporation
Specifications
Table 2‐1 lists specifications for the FP‐200 gun system components.
Table 2‐1 FP‐200 Specifications
Item Value
Types of Patterns
FP‐200 STD
FP‐200 RC
FP‐200 CF‐WP
Bead
Bead
Swirl/wide pattern
Maximum Operating Temperature 450 _F (230 _C)
Operating Air Pressure
(1)
STD, RC: 30 to 60 psi
(0.21 to 0.42 MPa)
CF/CF‐WP: 0 to 80 psi (0 to 0.55 MPa)
Maximum Air Consumption
CF‐WP: 90 L/m (3.2 cfm)
Maximum Hydraulic Pressure 1500 psi (10.34 MPa)
Extrusion Nozzle Orifice Diameter
(2)
Refer to Parts.
Electrical Requirements
160W at 240V
(supplied from applicator)
Swing Arm Length 3 feet (1 meter)
Mast Height 9 feet (2.74 m)
(1)
Recommended range. Dry, regulated, unlubricated air required for consistent
gun operation. Module performance and durability will be negatively affected if
operated outside the recommended range. Volumetric air requirements will vary
with gun configuration and application.
(2)
Nozzles must be specified and purchased separately. For reduced cavity
modules, nozzle diameter must be specified with gun purchase; nozzles are an
integral component of RC modules.
