Page #93 background imageLoading...
Page #93 background image
Parts
8-3
Part 237478_03
E 2012 Nordson Corporation
FP‐200 Gun Parts Lists
FP‐200 Swirl Gun (Side and Top Views)
Item Part Description Quantity Note
234 896 Gun, FP‐200, Swirl
NS 234 965 S Shield, Heat, FP‐200, Swirl 1
NS 276 644 S Clamp, Hose, 1.6in. x 1.874in. 12
NS 900 509 S Tubing, Polyethylene, 0.250 in. x 0.040 in., 50 ft 1
1 169 725 S Swivel, Ball, Multi‐Plane,
5
/
16
in. 1
2 344 896 S Elbow, Male,
1
/
4
in. x 10‐32 1
3 981 735 S Screw, Fillister, 6‐32 x 0.50 in. with Poly‐Lok 4
4 971 607 S Connector, 10‐32 x
1
/
4
in. 2
5 220 648 S Tubing, Air Supply, FP‐200 (High Temperature) 1
6 971 618 S Union, Tube,
1
/
4
in., Brass 1
7 981 083 S Screw, Pan, 8‐32 x 0.250 in., Slotted 2
8 983 011 S Washer, Lock, Internal, 8 6
9 971 605 S Elbow, Universal (Extrusion Air Line) 1
10 234 858 S Fitting, Hose, Barb, Swivel 1
11 234 889 S Trigger, Gun, FP‐200 1
12 985 216 S Pin, Dowel, 0.25 in. x 1.25 in. 1
13 271 620 S Spring, Wave, Safety 1
14 234 888 S Shell, Handgun, Left, FP‐200 1
15 234 887 S Shell, Handgun, Right, FP‐200 1
16 982 743 S Screw, Socket, 8‐32 x 1.375 in. 2
17 220 645 S Hose, Module, FP‐200 1
18 101 887 S Clamp, Tube, 0.228 in. 1
19 234 870 S Spacer, FP‐200 2
20 157 215 S Insulator, Mount 1
21 234 879 S Tube, Module, FP‐200 1
22 973 402 S Plug, Pipe, Socket, Flush,
1
/
8
in. (Opposite Side) 1
23 1108371 S Lubricant, Never‐Seez, NSF‐H1 Food Grade
24 973 403 S Plug, Pipe, Socket, Flush,
1
/
16
in. 2
25 1051687 S Module, ClassicBlue CF, WP 1
26 220 643 S Connector, Male, 0.125 in. x 0.125 in. 2
27 981 056 S Screw, Socket, 8‐32 x 0.750 in. 2
28 983 011 S Washer, Lock, Internal, 8 2
29 234 964 S Manifold, Air, FP‐200 1
30 234 880 S Tube, Manifold, FP‐200 1
Continued on next page
