Nordson FP-200 User Manual

Parts
8-4
Part 237478_03
E 2012 Nordson Corporation
FP‐200 Swirl Gun (Side and Top Views) (contd)
Item Part Description Quantity Note
31 157 205 S Body, Gun, FP‐200 (Service Block) 1
32 981 055 S Screw, Pan, 8‐32 x 0.250 in., Slotted 6
33 178 475 S Tag, Hot Surface 1
34 220 646 S Hose, Manifold, FP‐200 1
35 101 887 S Clamp, Tube, 0.228 1
36 174 881 S Cordset Assembly, FP‐200 with Eyelets 1
37 174 885 S Adhesive, Threadlocking –
38 234 882 S Regulator, Air, Miniature 1
39 234 883 S Bracket, Mounting 1
40 972 623 S Fitting, Barbed, Elbow,
1
/
4
in. x
1
/
8
in. 1
41 981 837 S Screw, Pan, 6‐32 x 0.375 in., Slotted 2
42 220 647 S Hose, Valve, FP‐200 1
43 234 894 S Fitting, 10‐32, T, Manifold 1
44 971 605 S Elbow, Universal (Swirl Air Line) 1
