$QQXQFLDWRU 2
S
WLRQV
Use Annunciator Selection screens to select information that will display on the ACS
annunciators. (Table 19 contains the ACS display selections.) Setting ACS=Y from the
Special Function screen (Figure 37) displays the Annunciator Selection 1 Screen,
address A1–A11.
)LJXUH  $QQXQFLDWRU 6HOHFWLRQ  6FUHHQ
.
)LJXUH  $QQXQFLDWRU 6HOHFWLRQ  6FUHHQ
The control panel’s annunciation points are divided into 23 ACS selection groups listed
in Table 19. Refer to Appendix A in the AFC-600 installation manual for a list of the 64
points within the ACS Selection Groups.
7DEOH  $&6 6HOHFWLRQ *URX
S
V
ACS Selection Group Annunciator Display
1 Programmable Annunciator #1
2 Programmable Annunciator #2
3 Programmable Annunciator #3
4 Programmable Annunciator #4
5 Programmable Annunciator #5
6 Programmable Annunciator #6
7 Programmable Annunciator #7
8 Programmable Annunciator #8
9 Programmable Annunciator #9
0 Programmable Annunciator #10
A 8 System points & Zones 1 - 56
B Zones 57 - 99, 8F Zones, 8R Zones, 4NACs
C Loop 1, Modules 1 - 64
D Loop 2, Modules 1 - 64
E Loop 1, Modules 65 - 128
F Loop 2, Modules 65 - 128
G Loop 1, Modules 129 - 159 & Loop 2, Modules 129 - 159
H Loop 1, Detectors 1 - 64
I Loop 2, Detectors 1 - 64
J Loop 1, Detectors 65 - 128
K Loop 2, Detectors 65 - 128
L Loop 1, Detectors 129 - 159 & Loop 2, Detectors 129 - 159
M Panel Circuits 1 - 1 to 8 - 8 (64)
Note
: Annunciator addresses 1 to 19 can be programmed to any one of the above selections. If
there is a UDACT, selections A-M will be sent to Annunciator addresses 20 to 32 respectively.
$1181 6(/(&7,21 $  $  $  $ 
$  $  $  $  $  $  $ 
$&6 6HOHFWLRQ *URX
S
$0   R U  QRW VH O HFW HG
$ $&6 $GGUHV V
$11181 6(/(&7,21 $  $  $ 
$  $  $  $  $  8'$&7 1
$&6 6HOHFWLRQ *URX
S
 RU  QRW VHOHFWHG
$ $&6 $ GGUH V V
,I 8'$&7 <
\
RX FDQ XVH DGGUHVVHV $$ ZLWK 8'$&7V KDYLQ
J
VRIWZDUH UHOHDVH 8'$&7
RU KL
J
KHU WR VHQG FRQWURO
S
DQHO VWDWX V WR D 8'$& 7 ,I 8'$&7 1 7 KH FRQWURO
S
DQHO GLV
S
OD
\
V WKH
$QQXQFLDWRU 6HOHFWLRQVFUHHQ DGGUHVVHV $$
