Notifier AFP-400 Installation Manual

 ,QVWDOODWLRQ Wiring a Signaling Line Circuit (SLC)
2-46 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
6W\OH  :LULQJ 2YHUYLHZ
Figure 2-64 shows typical wiring for a supervised and power-limited four-wire SLC
that meets NFPA 72-1993 Style 6 requirements. Table 2-19 contains the SLC
connections for this circuit:
Table 2-19 SLC Connections
6W\OH  :LULQJ 'LDJUDP
Figure 2-64 shows typical wiring for a Style 6 SLC:
)LJXUH  7\SLFDO )RXU:LUH 6/& &LUFXLW 6W\OH 
Connection SLC 1 SLC 2 (CPU-400 only)
SLC Out TB5-1 (+)
TB5-3 (–)
TB6-1 (+)
TB6-3 (–)
SLC Return TB5-2 (+)
TB5-4 (–)
TB6-2 (+)
TB6-4 (–)
&38 RQO\
&38
QR FRQQHFWLRQ
1RWH % %DVH ² )RU XVH
ZLWK 6'; &3; )'; ,3; DQG
/3; 6HULHV ,QWHOOLJHQW 'HWHFWRUV
