NRI v2 eagle - Eagle with 4-Fold Sorter

BA_v2_eagle_parallel_EN_1-0
13
Design
10 Interface–service/conguration
11 Interface – sorter override (BACTA)
12 Interface – machine (BDTA/BACTA)
13 Interface – 8-fold sorting adapter (option)
14 Switch blocks
15 Label – Switch block/coin channel assignment
(cf. Chap. 4.4 Label – switch functions/coin channel assignment, p. 17)
16 Status LED
1 Coin insert funnel
2 Coin return lever
3 Flight deck
4 Label
5 Locking lever for sorting cover
6 Closingdeviceforightdeck
7 Coin outlet – cash-box/sorting
8 Coin outlet – return
9 Mounting stud
Fig. 2: Design – v
2
eagle with 4-fold sorting mechanism
D
C
A
B
Return
1
3
4
2
5
6
7
8
9
4.1.2 v² eagle with 4-fold sorter
10
9
9
15
16
14
11
12
13
v² eagle BACTA
v² eagle BDTA
(not yet available)
