This chapter is intended to provide a general overview of the advantages and options of the
coin validator v
2
eaglewithparallelinterface.Therstsection,however,isdesignedtohelpyou
navigate easily within these operating instructions.
2.1 About these operating instructions
These operating instructions describe the design and operation of the electronic 5" coin validator
v
2
eagle with parallel BDTA or BACTA interface. Afterwards, chapters 6 and 7 explain the necessary
steps for starting up and operating the coin validator. Chapter 7 describes how to clean the coin
validator and remedy the cause of any malfunction.
Chap.10"Technicaldata"andtheappended"Index"reducethesearchforspecicexplanations.
2.1.1 Text conventions
To make it easier for you to navigate within these operating instructions and to operate the
device, the following accentuations were made in the text:
Safety instructions which you must observe in order to protect operators
and equipment.
Special notes intended to facilitate the use of the coin validator.
Atthebeginningofeachchapteryouwillndashort"guide"whichsummarizes
the contents of the chapter.
Device functions which are set or prepared by the manufacturer according
tocustomerspecicationsand canbe setor changedusing ourservice and
congurationtools(cf. Chap. 9 What subsequent settings can be made?, p. 42).
1 2 3 ... Requests to perform an action are numbered in a different typeface.
[Fig. 1/2] Cross-reference to an illustration. The number preceding the slash indicates the
numberofthegure,thenumberfollowingtheslashisthenumberoftheitem
inthegure.
