funcTion
5.7.3 Sorter override for tube-full signal via ...
5.7.3.1 ... Single inhibit lines of BDTA interface
If the machine control shall sort coins into the cash box chute or into an override sorting chute
when the external sorting device sends a "full" signal, the coin validator can be programmed in
the factory in such a way that, depending on the status of the single inhibit signal line 6 (pin 4)
(high/low), the single inhibit signal lines 1–5 either
• inhibit coins by default (single inhibit signal line 6 = low, single inhibit lines 1–5 = high) or
• sort the coins assigned to the single inhibit signal lines into the cash box (single inhibit
signal line 6 = high, single inhibit signal lines 1–5 = high)
(cf. Chap. 10.2.1 BDTA interface,
p. 46)
.
Cash box/override sorting path
The machine alternatively sends inhibit and sort signals to the coin validator via the single inhibit
signal lines if no coin is accepted. The information is stored by the coin validator whenever the
signal is present for at least 10 ms.
If the cash box chute is controlled via the single inhibit signal line 6, only ve
instead of six signal lines are available for coin acceptance and inhibiting.
5.7.3.2 ... Sorter override interface (only BACTA)
Via the 10-pole sorter override interface on the device rear side, the coin validator can receive
a tube-full signal for the four coin validator sorting chutes 1, 2, 3 and 5 or A, B, C, D, or for the
four manifold chutes A, B, C and D in order to enable steering of the coins to be sorted into a
full payout unit to the cash box or any alternative payout unit
(cf. Chap. 10.2.3 Sorter override interface
(only BACTA), p. 50)
.
The sorting destination in case of "tube full" depends on the respective sorting equipment and
conguration.
5.8 Teach mode (option)
If the v
2
eagle has been programmed accordingly in the factory, coin channels can be taught in
theteachmodewithoutcongurationsoftwareviatheswitchblockonthecoinvalidator,i.e.
a new token or coin is assigned to a coin channel. The new acceptance band is generated by
inserting the tokens/coins. It is not necessary to remove the coin validator from the machine
for this purpose. The last eight coin channels 9–16 (= teach channels) of the activated memory
block are available for teaching (cf. Chap. 7.3 Teaching coin channels in teach mode (optional), p. 37).
