Technical DaTa
10 Technical data
This chapter contains
• all relevant v
2
eagle data
• details concerning the machine interface
• information concerning v
2
eagle accessories
10.1 Device data
Supply voltage 10 V to 28 V DC
Current consumption max. Acceptance solenoid: approx. 3 W
when accepting coins Sorting solenoid: approx. 2 W (max. 2 at the same time)
U
nom
= 12 V Without sorting: approx. 400 mA (for approx 150 ms)
With sorting: approx. 800 mA (for approx. 250 ms)
U
nom
= 24 V Without sorting: approx. 300 mA (for approx 150 ms)
With sorting: approx. 600 mA (for approx. 250 ms)
Dielectric strength, in/outputs 28 V max.
Current load, outputs 10 mA max. (open collector)
Temperature range 0°C to 60°C
Temperature change Max. 0.2°C/min.
Rel. humidity up to 93%
Condensation not permitted
Machine interface BDTA
6coinsignaloutputs(opencollector)(activelow≤0.8V)
6singleinhibitsignalinputs(opencollector)(activehigh≥3.7V
(acceptance≤0.9V))
Commoninhibitsignalinput(opencollector)(activelow≤0.9V
(acceptance≥3.7V))
Returnsignaloutput(activelow≤0.8VatI=20mA)
For pin assignment refer to
Chap. 10.2.1 BDTA interface, p. 46
BACTA
5/6 coin signal outputs (push-pull, PNP/NPN transistor) (active high, VCOM
pos./active low VCOM neg.)
6singleinhibitsignalinputs(TTLcompatible,standby:high(5V))(≥3,7V
(acceptance≤0,9V))
For pin assignment refer to Chap. 10.2.2 BACTA interface, p. 48
Coin acceptance 32 coin types max. in 2 x 16 channels
Coin diameter 15–31 mm (optionally up to 32 mm, at 2.4-mm-thickness max.)
Coin thickness: 1.5–2.4 mm (optionally up to 3.4 mm)
Speed: 2 coins/s
