Table of conTenTs
BA_v2_eagle_parallel_EN_1-0
3
Table of contents
1 Revision protocol 7
2 About ... 8
2.1 About these operating instructions 8
2.1.1 Text conventions 8
2.1.2 Additional useful technical documentation 9
2.2 About the v
2
eagle 9
2.2.1 The v
2
eagle features 9
2.2.2 Models 10
2.2.2.1 Coin entry and return area 10
2.2.2.2 Internal 4-fold or 5-fold sorting mechanism 10
3 Safety instructions 11
3.1 Proper use 11
3.2 Protecting persons and equipment 11
4 Design 12
4.1 Overview 12
4.1.1 v² eagle with 5-fold in-line sorting mechanism 12
4.1.2 v² eagle with 4-fold sorter 13
4.2 Coin path (5-fold in-line sorter only) 14
4.3 Product label 15
4.3.1 Model number decoding 16
4.3.2 Data block decoding 16
4.4 Label – switch functions/coin channel assignment 17
4.5 Switch blocks 18
4.5.1 Switch functions – switch block S1 18
4.5.2 Switch functions – switch block S2 18
4.6 Coin return lever 19
4.7 Status LED (only v² eagle with 4-fold sorter) 19
4.8 Interfaces 19
